Baker Hughes has developed an acoustic acquisition, processing, and 3D visualization method that uses compressional body waves generated by an acoustic dipole source to better understand a fairly mature Gulf of Mexico play. This method, called deep compressional wave imaging (DCWI), enabled the operator to identify and determine the position of three fairly large faults, improve understanding of the structure above the salt dome, and define a future reservoir target. Integrating the acoustic data with induction logging data also identified an additional 30 ft (9.1 m) of pay in another target area.
Finding hidden targets
Interpreting seismic data in close proximity to structural features such as salt domes that have resulted from the movement of salt, or halokinesis, is well known and well documented throughout the history of drilling in the Gulf of Mexico. Halokinesis produces bedding disruption and complexity in the sediments surrounding the salt structures.
Because of the poor vertical resolution of surface seismic data, smaller targets that may hold economically viable reserves may not be easily imaged from the seismic data, and structural complexities such as faults and targets underlying the salt bodies may be missed entirely. Similarly, conventional borehole imaging services can only detect features at the intersection of the tool with the borehole, so outlying faults and fractures cannot be identified and critical formation details can be missed.
Deep reflection shear wave imaging (DSWI) overcomes this limitation by mapping acoustic reflections away from the borehole, even if they are not intersecting the wellbore. The DSWI service provides an image of the reflective feature, its distance away from the borehole, the magnitude of the reflection, and its strike orientation. The identified features can then be integrated into the reservoir model to aid in field development.
While typical DSWI methods can be employed, the DSWI range of investigation is limited because of the extreme low shear velocities of the sediments surrounding salt domes in the Gulf of Mexico.
An enabling innovation
Conventional DSWI tools have two types of sources: monopole and dipole. Initial borehole acoustic imaging relied on using the monopole source and focusing the analysis on the radiated compressional body waves that were reflected back to the borehole. This type of imaging could be used to determine imaged structures’ dip, but it did not provide any azimuthal information. More recent efforts with the monopole source have focused on using azimuthal receivers for directional sensitivity, but the tool size limits its use to high frequencies. These high frequencies and the accompanying formation attenuation severely limit the range of investigation.
DCWI is an innovative approach that uses the algorithm for DSWI and concentrates on the low frequency compressional body waves generated from a dipole source to offer an effective and efficient solution in unconsolidated formations surrounding salt domes. Using techniques similar to those used in seismic processing, reflections from formation features up to 100 ft (30.5 m) away from the borehole can be extracted from the cross-dipole shear waveform data.
The compressional body wave, generating from the dipole source, is also at a lower frequency than the monopole source, offering the ability to see deeper and with reduced attenuation effects since the wave’s attenuation is a function of the frequency raised to an exponential. The dipole’s directional radiation pattern, coupled with the four cross-component dipole information, enables optimization of the azimuthal sensitivity orientation. Although there is still the well-known conundrum of the 180° ambiguity associated with the dipole. This issue can be resolved through application of other information such as geologic knowledge, wellbore trajectory, or other information to determine the direction of returned reflected waves. Further enhancement is achieved by increasing the recording length by 70%, facilitating imaging deep into the formation, at depths of investigation of up to 100 ft or more, given the right conditions.
Gulf of Mexico case study
In an exploration project in the Gulf of Mexico, there was a large umbrella of uncertainty on the surface seismic as a result of a salt dome surrounded by unconsolidated sediments. A large fault was observed in the seismic data in the upper section, to the west of the study well. However, the fault was not discernible from seismic to the east, even after reprocessing of the seismic data. Using DCWI and processing the acoustic data for the compressional image, the fault could be seen to the east, striking northwestsoutheast with a dip of approximately 45°. After the acoustic data had been merged with the seismic data, it became possible to identify the position of the fault on the seismic section, aiding the understanding of the structure above the salt dome. This understanding will help in defining a future reservoir target. Once defined on the seismic, the throw of the fault was estimated to be around 50 ft (15 m), which corresponds to that seen on the compressional acoustic deep image.
Further processing for the amplitude of the acoustic data also enabled better bed definition, helping to improve the detail of the seismic in these unconsolidated formations, especially since the seismic around the salt dome is unclear and uncertain at depths and offsets around and above the dome. Additionally, the acoustic data were integrated with, and validated by, other log information.
DSWI helps operators gain insight of the reservoir structure with high-resolution images of formation features located up to 100 ft away from the borehole.
A 3D induction instrument was run to evaluate the possibility of laminated pay above the main section of interest in the well. Three sands were detected. The uppermost was easily identified as gasbearing from conventional log measurements, but the lower two sands were not easily detectable, and appeared as shales and with low resistivity. The results indicated, in spite of a significantly enlarged borehole, an additional 30 ft (9.1 m) of pay in these two lower sands. Although not the main exploration target, these sands are intended to be exploited in other parts of the field.
In addition to the laminated pay, and again in spite of large washouts, the 3D induction was processed in high-salinity mud to determine structural dips, confirming the structural dips to be in general less than 10°. This corresponded to the observations from the seismic and field expectations. However, the dip processing also indicated several intervals of complex growth faults and associated discontinuities, and these corresponded with the reflectors seen on the DCWI.
With the 3D induction results, the fault could only be seen near the wellbore. With the processed compressional wave image, it was possible to determine the dip and strike of the reflector as far as 89 ft (27 m) away from the borehole. Some of the complexity around the fault could also be seen.
Overall, the DCWI method identified three fairly large faults, with one subseismic fault and several other small faults of discontinuities. The gas- or light hydrocarbon- bearing sand above the lowresistivity pay was visible on the DCWI because the compressional wave is sensitive to hydrocarbons.
Future development
Future development of the DCWI service is being extended to a 3D volume, enabling visualization of the salt dome and associated structures. In horizontal wells, this 3D visualization enables detection of layers above and below the wellbore as well as reflectors often associated with natural fractures and faults, both intersecting and non-intersecting with the borehole.
Future integration of this technology with vertical seismic profiles and borehole image logs is expected to further improve the level of detail regarding the structure complexity at the wellbore and penetrating into the formation. Consequently, greater refinement of the seismic picture will be possible, making exploration and development objectives easier and more efficient to achieve.
